SPECTRONIGHT D2L-31F

Binocular Goggle System

See beyond the dark.

Advanced Dual-Sensor Technology
D2L-31F Image 0
D2L-31F Image 1
D2L-31F Image 2
D2L-31F Image 3
D2L-31F Image 4
D2L-31F Image 5
D2L-31F Image 6
D2L-31F Image 7
D2L-31F Image 8
D2L-31F Image 9
D2L-31F Image 10
D2L-31F Image 11

Advanced Night Vision System

Key Features:

  • Dual Sensor Technology (Low Light + Thermal)
  • 800×600 OLED Display Resolution
  • Up to 32 Hours Operation Time
  • IP67 Weather Protection
  • Standard Wilcox Interface
Contact us for pricing
Professional equipment - Certification may be required

D2L-31F Advanced Capabilities

Advanced fusion sight technology combining digital low-light and infrared observation for superior tactical performance

18μm BSI CMOS Sensor
High Sensitivity Mode
Dark Starlight Technology
Ultra Low Latency - 100 FPS
Day & Night Operation
Aspherical Lens System
Refractive Index Lens
IP67 Water & Dust Protection
HDR Technology
iOS & Android Support
Mission Recording
Fast Lens F/1.05
12μm LWIR Sensor
Stereoscopic Binocular Vision
Digital Compass
Advanced Wireless Connectivity
Wireless Video Streaming
IR Anti-Reflection Coating

Click on any feature icon above to explore the D2L-31F fusion system's advanced capabilities

Pro Tip:

Product Description

The SPECTRONIGHT Binocular Goggle represents the pinnacle of night vision technology, combining advanced low-light and thermal imaging capabilities in a single, lightweight system. Engineered for professional and tactical applications, this cutting-edge device delivers unparalleled performance in complete darkness.

Advanced Dual-Sensor Technology

Featuring both low-light intensification and thermal imaging sensors, the SPECTRONIGHTprovides comprehensive situational awareness across the entire electromagnetic spectrum. The low-light sensor excels in ambient light conditions, while the thermal sensor ensures clear vision regardless of lighting conditions.

Professional Grade Construction

Built with a magnesium-aluminum alloy housing, the system weighs only 535g while maintaining IP67 weather protection. The ergonomic design ensures comfortable extended use during long missions or surveillance operations.

Extended Operation Capability

Powered by four 18650 rechargeable lithium batteries, the SPECTRONIGHTdelivers up to 32 hours of continuous operation. The quick boot time of ≤4 seconds ensures rapid deployment when time is critical.

Superior Detection Range

With detection ranges extending beyond 1200 meters for vehicles and 900 meters for human targets, the SPECTRONIGHTprovides unmatched long-range surveillance capabilities for professional applications.

Technical Specifications

Sensor Specifications

Parameter Low Light Infrared
Image Sensor Dimension 1 inch -
Spectral Response Range 400nm~1100nm 8μm~14μm
Image Resolution 800×600 640×512
Pixel Size 18μm 12μm
Minimum Illumination 0.00005 Lx -

Optical Parameters

Objective Lens FL:

Low Light: 19.8mm

Infrared: 10.6mm

F/#:

Low Light: F1.05

Infrared: F1.0

FOV:

50° × 40° × 30°

Exit Pupil:

8mm

Exit Relief:

23mm

Min. Focus:

250mm

System Parameters

Boot Time: ≤ 4s
Operation Time: ≤ 32 hours
Weight (Goggle): ≤ 535g
System Weight: ≤ 1080g
Protection: IP67
Size: 107×105×89mm
Interface: Wilcox Standard
Connection: Type-C

Detection Ranges

Human Targets (DRI)

Detection: 935m
Recognition: 468m / 234m
Identification: 751m / 375m / 188m

Vehicle Targets (DRI)

Detection: 1265m
Recognition: 633m / 316m
Identification: 1016m / 508m / 254m
